DESCRIPTION

Basic Info.

Model NO.	SY-V006N
Objective Lens	1X
Material	Plastic
Warranty	1 Year
Transport Package	Carton Box
Trademark	Sunnymed
Origin	China
Production Capacity	200 Set/Month

Product Description

SY-V006N Desktop Medical Veterinary Slit Lamp Clinical machine for animals pets

High luminance: white LEDNet weight: 700g, very light and portableLit Width is continuously variableCompact design enables inspection before/after operation at the patient's sideApplication in a wide range of situations; from rounds in and outside hospital to screening of children and studentsOn/Off switch easy operated by finger's topBattery drive: 2 hours of continuous operation possible with a battery( in full charged state with maximum illumination)

Microscope
Eyepiece	10X and 16X
Objective Lens	1X
Total magnification	10X and 16X
Diopter adjustment	±5D
Visual Field	10mm
Pupil Distance adjustment	50-75mm(at eyepiece 10X)55-70mm(at eyepiece 16X)
Working Distance (WD)	78 mm
Illumination
Slit Width :	0-Ø10mm
Slit Length :	Ø1mm, Ø3mm, Ø5mm,Ø10mm
Filter:	Cobalt blue, Green, Color temperature conversion filter
Illumination Angle:	On the level circumference 30 degree
Light Source:	High brightness white LED
Battery
Type	Rechargeable lithium-ion battery
Rated Capacity	7.4V/680mAh
Operation Time	About 2 hours(at full charge with maximum illumination)
Battery Charger
Rated Input	AC 100-240V 50/60Hz
Charging Output	DC 804V/600mA
General
Dimensions:	159mm(W)x 107mm(D)x231mm(H)
Weight:	About 700g
Electric Shock Protection Type	Internal Battery Type
Electric Shock Protection Degree	Type B
